D2P-C
Integrated traction and pump control, with a maximum traction output current of 100A and pump output current of 45A. Mainly used in electric pallet trucks.
Integrated traction and pump control, with a maximum traction output current of 100A and pump output current of 45A. Mainly used in electric pallet trucks.
FEATURES
Application
Functional integrity
1. 5 x Input Switch, 2 x NPN Output, Voltage Throttle.
2. Build-in regenerate break to recycle energy and charge to battery when motor stop working.
3. Advanced motor control algorithm provides smooth starting on a ramp.
4. Traction and pump intergrated controller with compated size, high performance value.
Robust Safety and Reliability
1. Advanced MOSFET power section for smooth andseamless control.
2.Electronics sealed and heat transfer design.
3.Faulty detection, prevent over-voltage, undervoltage, overcurrent, over-heat.
Simple & Flexible
1.Simple wiring, easy to install
2.On-premise or remote upgrade
3.PC Windows programming and powerful system diagnostic tools.
Specification
| Items | Specifications |
| Product Number | D2P-C |
| 10s output Current Rating (Arms) | Traction:100A ; Pump:45A |
| 1Min output Current Rating (Arms) | Traction:55A ; Pump:20A |
| 60Min output Current Rating (Arms) | Traction:35A |
| Application | Brushed DC Motor |
| Communication | Serial |
| Voltage | 24VDC |
| Operating Temperature | -30°C ~ +55°C |
Note: 60 Min RMS Current Rating is measured under proper heat-sink assistance.
